Available
Ruthmann T570HF
Truck mounted
access platform
RuthmannT570HF
57m truck mounted cherry picker, supplied with an operator · See all 50m cherry pickers
57mWorking height
41mOutreach
600kgSWL
Ruthmann T570HF truck mounted platform — 57m working height, 41m outreach and a 600kg safe working load. Material lifting up to 300kg.
Choose your dates
This machine is priced on application. Send your dates through and we'll come back with a quote.
Full specification
Download Specification SheetManufacturerRuthmann
Max working height57m
Max outreach41m
Safe working load600kg
Gross vehicle weight26t
Max cage floor height55.00m
Width - transport position2.55m
Height - transport position3.90m
Length - transport position11.90m
Standard cage width2.42m
Work cage height1.10m
Work cage depth0.97m
Extended cage width3.82m
Work cage rotation2x250°
Material lifting optionsUp to 300kg
Max ground inclination (side to side)5°
Max ground inclination (front to back)5°
Max rated wind speed12.5m/s - 28mph
Available depots
PricePrice on application
Working envelope
