RuthmannTU285

28.5m truck mounted cherry picker, supplied with an operator · See all 30m cherry pickers

28.5mWorking height

20.5mOutreach

320kgSWL

Ruthmann TU285 truck mounted platform — 28.5m working height, 20.5m outreach and a 320kg safe working load.

Choose your dates

Start date

Start time

End date

End time

This machine is priced on application. Send your dates through and we'll come back with a quote.

ManufacturerRuthmann

Max working height28.5m

Max outreach20.5m

Safe working load320kg

Gross vehicle weight7.49t

Max cage floor height26.50m

Width - transport position2.50m

Height - transport position3.69m

Length - transport position6.96m

Standard cage width1.40m

Work cage height1.10m

Work cage depth0.86m

Extended cage widthN/A

Work cage rotation2x90°

Material lifting optionsN/A

Max ground inclination (side to side)5°

Max ground inclination (front to back)5°

Max rated wind speed12.5m/s - 28mph

Available depots

PricePrice on application
